Product code: MT-171803-NF

1.71GHz to 1.88GHz 3dBi Vertical Omni Directional Outdoor Antenna N-Female

Product Overview
Part Number MT-171803-NF
Gain 3 dBi
Dimension 250x70x55mm
Weight 270g
Connector N-Female
Beam-width Horz.360 deg Vert.67 deg



WhatsApp Chat
Skype
Product Part Number
MT-171803-NF
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range1710 to 1880MHz
V.S.W.R (MAX)1.3:1
Antenna TypeCollinear
RadiationOmni Directional
Gain (MAX)3 dBi
PolarizationVertical
Maximum Power50 Watts
Vertical Beam-width78 Deg
Horizontal Beam-width360 Deg
Impedance50 Ohm
Antenna DesignDipole Array Dipole
Internal MaterialCopper
ConnectorN-Female
Mechanical
Length (MAX)250 mm
Diameter (MAX)70 x 55mm
Antenna Weight (G.W)200 g
Accessories (G.W)70 g
ApplicationIndoor / Outdoor
Radome MaterialWhite Fiberglass
Parts MaterialAluminium
Mount StylePole Mount / Wall Mount
Pole Mounting32mm to 45mm
MountingStainless Steel
Wind SurvivalGreater than 150MPH
Storage Temperature-40 to +80
Operating Temperature-40 to +60
Operating Humidity10%~90% non-condensing
Storage Humidity5%~90% non-condensing
Safety, Emission and otherCE, FCC, RoHS
