Product code: MT-172103-NF

1.71GHz to 2.17GHz 3dBi Vertical Broadband Omni Directional Outdoor Antenna

Product Overview
Part Number MT-172103-NF
Gain  3 dBi
Dimension 250x70x55mm
Weight 300g
Connector N-Female
Beam-width Horz.360 deg Vert.67 deg



WhatsApp Chat
Skype
Product Part Number
MT-172103-NF
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range1710 to 2170MHz
V.S.W.R (MAX)2.0:1
Antenna TypeCollinear
RadiationOmni Directional
Gain (MAX)3 dBi
PolarizationVertical
Maximum Power200 Watts
Vertical Beam-with67 Deg
Horizontal Beam-with360 Deg
Impedance50 Ohm
Antenna DesignDipole Array Dipole
Internal MaterialCopper
ConnectorN-Female
Mechanical
Length (MAX)250 mm
Diameter (MAX)70 x 55mm
Antenna Weight (G.W)230 g
Accessories (G.W)70 g
ApplicationIndoor / Outdoor
Radome MaterialWhite Fiberglass
Parts MaterialAluminium
Mount StylePole Mount / Wall Mount
Pole Mounting32mm to 45mm
MountingStainless Steel
Wind SurvivalGreater then 150MPH
Storage Temperature-40 to +80
Operating Temperature-40 to +60
Operating Humidity10%~90% non-condensing
Storage Humidity5%~90% non-condensing
Safety, Emission and otherCE, FCC, RoHS
