Product code: MT-111210-NF

1080MHz to 1200MHz 10dBi Omni Directional Outdoor Antenna N-Female

Product Overview
Part Number MT-111210-NF
Dimension 1580x70x50mm
Weight 1120g
Connector N-Female
Beam-width Horz.360 deg Vert.10 deg
WhatsApp Chat
Skype
Product Part Number
MT-111210-NF
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range1080 to 1200MHz
V.S.W.R (MAX) 1.5:1
Antenna TypeCollinear
RadiationOmni Directional
Gain (MAX)10 dBi
PolarizationVertical
Maximum Power50 Watts
Vertical Beam-with10 Deg
Horizontal Beam-with360 Deg
Impedance50 Ohm
Antenna DesignDipole Array
Internal MaterialCopper
ConnectorN-Female
Mechanical
Length (MAX)1580mm
Diameter (MAX)70 x 55mm
Antenna Weight (G.W)1050 g
Accessories (G.W)70 g
ApplicationIndoor / Outdoor
Radome MaterialWhite Fiberglass
Parts MaterialAluminium
Mount StylePole Mount / Wall Mount
MountingStainless Steel
Wind SurvivalGreater then 150MPH
Storage Temperature-20 to +80
Operating Temperature-20 to +60
Operating Humidity10%~80% non-condensing
Storage Humidity5%~80% non-condensing
Safety, Emission and otherCE, FCC, RoHS
