Product code: MT-202302-NM

2.0GHz to 2.3GHz 2dBi Outdoor Mini OMNI Directional Antenna

Product Overview
Part Number MT-202302-NM
Dimension 150x20x20mm
Weight 110g
Connector N-Female
Beam-width Horz.360 deg Vert.48 deg



WhatsApp Chat
Skype
Product Part Number
MT-202302-NM
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range2000 to 2300MHz
V.S.W.R (MAX)1.5:1
Antenna TypeCollinear
RadiationOmni Directional
Gain (MAX)2 dBi
PolarizationVertical
Maximum Power50 Watts
Vertical Beam-width48 Deg
Horizontal Beam-width360 Deg
Impedance50 Ohm
Antenna Design1/4 Wavelength Dipole
Internal MaterialCopper
ConnectorN-Male
Mechanical
Length (MAX) 150mm
Diameter (MAX)20 x 20mm
Antenna Weight (G.W)110g
Accessories (G.W)5g
ApplicationIndoor / Outdoor
Radome MaterialWhite Fiberglass
Parts MaterialAluminum
Wind SurvivalGreater than 150MPH
Storage Temperature -40 to +80
Operating Temperature-40 to +60
Operating Humidity10%~90% non-condensing
Storage Humidity5%~90% non-condensing
Safety, Emission and otherCE, FCC, RoHS
