Product code: MT-202303-NM

2.0GHz to 2.3GHz 3dBi Outdoor Mini OMNI Directional Antenna (N-Male)

Product Overview
Part Number MT-202303-NM
Dimension 183x20x18mm
Weight 95g
Connector N-Female
Beam-width Horz.360 deg Vert.48 deg



WhatsApp Chat
Skype
Product Part Number
MT-202303-NM
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range2000 to 2300MHz
V.S.W.R (MAX)1.3:1
Antenna TypeCollinear
Radiation Omni Directional
Gain (MAX)3 dBi
PolarizationVertical
Maximum Power50 Watts
Vertical Beam-width48 Deg
Horizontal Beam-width360 Deg
Impedance50 Ohm
Antenna Design1/2 Dipole Array
Internal MaterialCopper
ConnectorN-Male
Mechanical
Length (MAX)183mm
Diameter (MAX)20 x 18mm
Antenna Weight (G.W)95 g
Accessories (G.W)5 g
ApplicationIndoor / Outdoor
Radome MaterialWhite Fiberglass
Ground MaterialAluminium
Wind SurvivalGreater than 150MPH
Storage Temperature-40 to +80
Operating Temperature-40 to +60
Operating Humidity10%~90% non-condensing
Storage Humidity5%~90% non-condensing
Safety, Emission and otherCE, FCC, RoHS, ISO
