Product code: MT-222315-NF

2.2GHz to 2.3GHz 15dBi Outdoor OMNI Directional Antenna

Product Overview
Part Number MT-222315-NF
Dimension 1650x70x50mm
Weight 1270g
Connector N-Female
Beam-width Horz.360 deg Vert.5 deg



WhatsApp Chat
Skype
Product Part Number
MT-222315-NF
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range2200 to 2300MHz
V.S.W.R (MAX)1.3:1
Antenna TypeCollinear
RadiationOmni Directional
Gain (MAX)15 dBi
PolarizationVertical
Maximum Power50 Watts
Vertical Beam-width5 Deg
Horizontal Beam-width360 Deg
Impedance50 Ohm
Antenna DesignDipole Array
Internal MaterialCopper
ConnectorN-Female
Mechanical
Length (MAX)1650mm
Diameter (MAX)70 x 55mm
Antenna Weight (G.W)1200 g
Accessories (G.W)70 g
ApplicationIndoor / Outdoor
Radome MaterialWhite Fiberglass
Parts MaterialAluminium
Mount StylePole Mount / Well Mount
MountingStainless Steel
Wind SurvivalGreater than 150MPH
Storage Temperature-20 to +80
Operating Temperature-20 to +60
Operating Humidity10%~80% non-condensing
Storage Humidity5%~80% non-condensing
Safety, Emission and otherCE, FCC, RoHS
