Product code: 26P-698-3800F-17G-65H8V

26-Port, TDD Hybrid Panel Antenna, 65° HBW, (2x) 698-960 / (2x) 1427-2690 /2300-2690 / 3300-3800 MHz, 16.5/16.5/18/18/17/17 dBi, 2-12°T, 2.597 m

25-Port Antenna

R1

 R2 Y1 Y2 Y3

P1
Frequency Range (MHz)

698-960

 698-960 1427-2690 1427-2690 2300-2690

3300-3800
HBW

65°

 65° 65° 65° 65°

65°
Gain

16.5 dBi

 16.5 dBi 18 dBi 18 dBi 17 dBi

17 dBi
Tilt

2-12°

 2-12° 2-12° 2-12° 2-12°

2-12°
Connectors

(other connectors by request)

(2x) 4.3/10

Female

 (2x) 4.3/10

Female

 (2x) 4.3/10

Female

 (2x) 4.3/10

Female

 (1x)MQ5 Male+ (1x) MQ4 Male (1x)MQ5 Male+ (1x) MQ4 Male
WhatsApp Chat
Skype
Product Part Number
26P-698-3800F-17G-65H8V
Electrical & Mechanical Specification
Electrical Specifications
R1 / R2Y1 / Y2
Frequency RangeMHz698-9601427-2690
MHz698-806790-894880-9601427-15181695-19201920-21702300-24002500-2690
Polarization—±45°±45°
Gainat Mid TiltdBi15.816.116.415.716.617.217.417.4
Over All TiltsdBi15.6 ± 0.515.9 ± 0.516.2 ± 0.515.5 ± 0.616.4 ± 0.517.0 ± 0.517.2 ± 0.517.2 ± 0.5
Horizontal Beamwidthdegree66 ± 6.562 ± 6.058 ± 6.570 ± 8.066 ± 8.065 ± 7.061 ± 6.561 ± 8.0
Vertical Beamwidthdegree8.4 ± 0.87.8 ± 0.67.2 ± 0.68.1 ± 0.66.6 ± 0.85.9 ± 0.65.2 ± 0.54.8 ± 0.6
Electrical Downtilt, Continuously Adjustabledegree2-122-12
First Upper Side Lobe SuppressiondB> 15> 15> 15> 15> 15> 15> 15> 15
Front-To-Back Ratio Co-Polar ±30°dB> 23> 24> 25> 22> 24> 25> 23> 23
Cross Polar Discrimination At BoresightdB> 17> 18> 17> 15> 16> 16> 16> 16
IsolationCross-PolardB> 25> 25
Interband (typical)dB> 25> 25
ImpedanceOhm5050
VSWR—< 1.5< 1.5
Return LossdB> 14> 14
PIM3 (2×43 dBm Carrier)dBc< -150< -150
Lightning Protection—DC GroundDC Ground
Maximum Average Input Power per Port, at 50° C Ambient TemperatureWatts250200
TDD LTE Electrical SpecificationsY3
Frequency RangeMHz2300-2690
MHz2300-24002490-2690
Polarization—±45°
Electrical Downtilt, Continuously Adjustabledegree2-12
Single Column BeamGaindBi15.5 ± 116 ± 1
Horizontal Beamwidthdegree80 ± 1575 ± 15
Vertical Beamwidth (3 dB)degree6.0 ± 0.65.5 ± 0.6
Cross-Polar Discrimination At Boresight (0°)dB1616
First Upper Side Lobe SuppressiondB≥ 16≥ 16
Front-To-Back Ratio, Co-Pol ±30°dB≥ 25≥ 25
65° Broadcast BeamGaindB16.517
Horizontal Beamwidth (10 dB)degree115108
Vertical Beamwidth (3 dB)degree6.0 ± 0.65.5 ± 0.6
Cross-Polar Discrimination At Boresight (0°)dB1616
First Upper Side Lobe SuppressiondB≥ 16≥ 16
Front-To-Back RatiodB≥ 25≥ 25
Service Beam0° Direct Beam GaindBi2020.5
0° Direct Beam Horizontal 3 dB Beamwidthdegree2624
0° Direct Beam Cross-Polar RatiodB1818
0° Direct Beam Front-To-Back Ratio, Co-PolardB≥ 28≥ 28
0° Direct Beam Horizontal Sidelobe SuppressiondB1212
±30° Direction Beam GaindBi18.519
±30° Direction Beam Horizontal 3 dB Beamwidthdegree2926
±30° Direction Beam Front-To-Back Ratio, Co-PolardB≥ 28≥ 28
Soft Split Multi-BeamGaindBi1919.5
Horizontal Beamwidth (3 dB)degree3028
Vertical Beamwidth (3 dB)degree6.0 ± 0.65.5 ± 0.6
First Upper Side Lobe SuppressiondB≥ 16≥ 16
Front-To-Back Ratio, Co-PolardB≥ 25≥ 25
Coupling Factor Between Calibration And Each AntennadB-26 ± 2
Calibration and Electrical ParameterPort
Maximum Amplitude Tolerance From Calibration Port To Input PortsdB≤ 1.0
Maximum Phase Tolerance From Calibration Port To Input Portsdegree≤ 9
Ports VSWR—< 1.5
Return LossdB> 14
Average Power CapacityW50
Co-Polar Isolation Bewtween PortsdB≥ 25
Inter-band IsolationdB≥ 25
PIM3 (2×43 dBm Carrier)dBc< -143
ImpedanceOhms50
Lightning Protection—DC Ground
TDD LTE Electrical SpecificationsP15G Electrical Specifications
Frequency RangeMHz3300-3800Frequency RangeP1
MHz3300-36003600-3800MHz3300-3800
Polarization—±45°SingleGainMHz3300-36003600-3800
Electrical Downtilt, Continuously Adjustabledegree2-12Column BeamHorizontal Beamwidth (3 dB)dBi15.1 ± 115.5 ± 1
Single Column BeamGaindBi15.1 ± 115.5 ± 1Vertical Beamwidth (3 dB)degree75 ± 1570 ± 15
Horizontal Beamwidthdegree75 ± 1570 ± 15Cross-PolarAt Boresight (0°)degree6.6 ± 0.86.0 ± 0.6
Vertical Beamwidth (3 dB)degree6.6 ± 0.86.0 ± 0.6DiscriminationOver SectordB≥ 15≥ 15
Cross-PolarAt Boresight (0°)dB≥ 15≥ 15First Upper Side Lobe SuppressiondB≥ 8≥ 8
DiscriminationOver SectordB≥ 8≥ 8Broadcast BeamGaindB≥ 15≥ 15
First Upper Side Lobe SuppressiondB≥ 15≥ 15(± 13°, ± 43° Service Beam)Horizontal BeamwidthdB2020.5
Front-To-Back RatiodB≥ 23≥ 23First Upper Side Lobe Suppressiondegree6565
65° Broadcast BeamGaindB16.517Front-To-Back RatiodB≥ 15≥ 15
Horizontal Beamwidth (10 dB)degree115108Service Beam0° Direct Beam GaindB≥ 25≥ 25
First Upper Side Lobe SuppressiondB≥ 15≥ 150° Direct Beam Horizontal 3 dB BeamwidthdBi20.521
Front-To-Back Ratio, Co-PolardB≥ 25≥ 250° Direct Beam Cross-Polar Ratio atdegree2624
Service Beam0° Direct Beam GaindBi20.521BeampeakdB≥ 16≥ 17
0° Direct Beam Horizontal 3 dB Beamwidthdegree26240° Direct Beam Front-To-Back
0° Direct Beam Cross-Polar Ratio at BeampeakdB≥ 16≥ 17Ratio, Co-PolardB≥ 27≥ 28
0° Direct Beam Front-To-Back Ratio, Co-PolardB≥ 27≥ 280° Direct Beam Horizontal Sidelobe
0° Direct Beam Horizontal Sidelobe SuppressiondB1212dB1212
±30° Direction Beam GaindBi1919.5
±30° Direction Beam Horizontal 3 dB Beamwidthdegree2825
±30° Direction Beam Front-To-Back Ratio, Co-PolardB≥ 25≥ 25
Soft Split Multi-BeamGaindBi19.319.8
Horizontal Beamwidth (3 dB)degree3129
Front-To-Back Ratio, Co-PolardB≥ 25≥ 25
Coupling Factor Between Calibration And EachdB-26 ± 2
Calibration and Electrical ParameterAntenna Port
Maximum Amplitude Tolerance From Calibration Port To Input PortsdB≤ 1.0
Maximum Phase Tolerance From Calibration Port To Input Portsdegree≤ 9
Ports VSWR—< 1.5
Average Power CapacityW25
Co-Polar Isolation Bewtween PortsdB≥ 23
Inter-band IsolationdB≥ 23
ImpedanceOhms50
Lightning Protection—DC Ground
Integrated RET Specifications
ProtocolsCompliant to AISG v2.0 and 3GPP
Supply Voltage Range10-30 V DC; Compliant to AISG2.0 and 3GPP TS25.461 V6.0.0
PowerStandby< 2 W
ConsumptionIn Motion< 10 W
Connectors2 x 8 Pin Circle Connector According to IEC 60130-9 and AISG Daisy Chain In: Male; Daisy Chain Out: Female
Pin3: RS485B; Pin5: RS485A; Pin6: 10-30 V; Pin7: DC Return
Female Connector: 8 PINs; Male Connector: 4 PINs
Lightning Protection RatingIEC 61000-4-5 Current Pulse Profile
Line to Ground: 8/20 µs @ 8 kA ≥ ±5 Repititions Line to Line: 8/20 µs @ 3 kA ≥ ±5 Repititions
Safety StandardCompliant to EN 60950/UL 60950/RoHS, CE
Mechanical Specifications
Connector Type—(8x) 4.3/10 Female & (2x)MQ5 Male+ (2x) MQ4 Male
Connector Position—Bottom
Electrical Tilt Control—Integrated RET
Radome Material—Fiberglass
Antenna Dimensions (H x W x D)mm (in)2597 x 497 x 197 (102.2 x 19.6 x 7.8)
Antenna WeightAntenna Onlykg (lbs)43 (94.8)
with Clampskg (lbs)52 (114.6)
Maximum Wind Speedkm/h (mph)200 (124.3)
Wind LoadFrontalN (lbf)1195 (268.6)
at 150 km/hRearN (lbf)1335 (300.1)
LateralN (lbf)585 (131.5)
Operating Temperature°C (°F)-40 to +60 (-40 to +140)
