Product code: MT-545915-NF

5.425 GHz to 5.875 GHz 15dbi Omni Directional Outdoor Antenna

Product Overview
Part Number MT-545915-NF
Dimension 745x70x50mm
Weight 550g
Connector N-Female
Beam-width Horz.360 deg Vert.5 deg



WhatsApp Chat
Skype
Product Part Number
MT-545915-NF
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range5425 to 5875MHz
V.S.W.R (MAX)1.5:1
Antenna TypeCollinear
RadiationOmni Directional
Gain15 dBi
PolarizationVertical or Horizontal
Maximum Power100 Watts
Vertical Beamwidth5 Deg
Horizontal Beamwidth360 Deg
Impedance50 Ohm
Antenna DesignDipole Array
Internal MaterialCopper
ConnectorN-Female
Mechanical
Length 745 mm
Diameter70 x 50mm
Antenna Weight480 g
Accessories 70 g
ApplicationIndoor / Outdoor
Radome MaterialWhite Fiberglass
Mount StylePole Mount / Well Mount
Parts MaterialAluminum
MountingStainless Steel
Wind SurvivalGreater than 150MPH
Storage Temperature-40 to +80
Operating Temperature-40 to +60
Operating Humidity10%~90% non-condensing
Storage Humidity5%~90% non-condensing
Safety, Emission and otherRoHS, CE, FCC, WEEE
