Product code: MT-DTA846
5900-7125MHz Cavity Band Pass Filter
- P/N：MT-DTA846
- Pass Band Frequency：5900-7125MHz
- Stop Band Rejection:≥80dB
- Connectors：SMA-Female
Product Part Number
MT-DTA846
Electrical & Mechanical Specification
| S/N | Item | Parameters |
|---|---|---|
| 1 | Center Frequency(F0) | 6512.5MHz |
| 2 | Pass Band Frequency | 5900 ~ 7125MHz |
| 3 | Pass Band Insertion Loss | ≤0.9dB |
| 4 | Pass Band Ripple | ≤0.45dB |
| 5 | Pass Band Return Loss | ≥23dB |
| 6 | Stop Band Rejection | ≥80dB @ DC ~ 5260MHz ≥50dB @ 5260 ~ 5500MHz |
| 7 | Impedance | 50 Ohms |
| 8 | Power Handling | 5.0W Max. |
| 9 | Connectors | SMA-Female |
