6-Port, Panel Sector Antenna, 65° HBW, 698-960/(2x) 1710-2690 MHz, 13/16/16 dBi, 2-12°T, 0.997 m

Product code: 6P-698-2690F-16G-65H7V

6-Port, Panel Sector Antenna, 65° HBW, 698-960/(2x) 1710-2690 MHz, 13/16/16 dBi, 2-12°T, 0.997 m

6-Port Antenna	R1	Y1	Y2
Frequency Range	698-960 MHz	1710-2690 MHz	1710-2690 MHz
HBW	65°	65°	65°
Gain	13 dBi	16 dBi	16 dBi
Tilt	2-12°	2-12°	2-12°
Connectors (other connectors by request)	(2x) 4.3/10 Female	(2x) 4.3/10 Female	(2x) 4.3/10 Female

WhatsApp Chat

Skype

Product Part Number

6P-698-2690F-16G-65H7V

Electrical & Mechanical Specification

Electrical Specifications
			R1			Y1 / Y2
Frequency Range		MHz	698-960			1710-2690
Frequency Range		MHz	698-806	790-894	880-960	1710-1880	1850-1990	1920-2170	2300-2400	2490-2690
Polarization		—	±45°			±45°
Gain	at Mid Tilt	dBi	12.5	13	13.3	15.2	15.5	15.7	16.1	16.2
Gain	Over All Tilts	dBi	12.5 ± 0.5	13.0 ± 0.5	13.3 ± 0.5	15.1 ± 0.7	15.4 ± 0.7	15.6 ± 0.7	16.0 ± 0.7	16.1 ± 0.7
Horizontal Beamwidth		degree	70 ± 5	68 ± 5	65 ± 5	69 ± 6.0	67 ± 6.0	66 ± 5.5	66 ± 5.5	64 ± 5.0
Vertical Beamwidth		degree	22.2 ± 3.0	19.8 ± 2.0	18.6 ± 2.0	9.8 ± 1.0	9.1 ± 0.9	8.6 ± 0.9	7.6 ± 0.8	6.9 ± 0.7
Electrical Downtilt, Continuously Adjustable		degree	2-Dec			2-Dec
Tilt Accuracy		degree	< 1.5	< 1.5	< 1.5	< 1	< 1	< 1	< 1	< 1
First Upper Side Lobe Suppression		dB	> 15	> 15	> 15	> 15	> 15	> 15	> 15	> 15
Front-To-Back Ratio ±30°		dB	> 23	> 24	> 24	> 23	> 24	> 24	> 25	> 25
Cross Polar	at Boresight	dB	> 17	> 17	> 17	> 16	> 16	> 16	> 17	> 17
Discrimination	Over Sector	dB	> 8	> 8	> 8	> 8	> 7	> 8	> 8	> 5
Isolation	Cross-Polar	dB	> 25			> 25
	Port-To-Port	dB	> 25			> 25
	Interband		> 25			> 25
Impedance		Ohm	50			50
VSWR		—	< 1.5			< 1.5
Return Loss		dB	> 14			> 14
PIM3 (2×43 dBm Carrier)		dBc	< -150			< -150
Lightning Protection		—	DC Ground			DC Ground
Maximum Average Input Power per Port, at 50° C Ambient Temperature		Watts	250			200

Integrated RET Specifications
Protocols		Compliant to AISG v2.0 and 3GPP
Supply Voltage Range		10-30 V DC; Compliant to AISG2.0 and 3GPP TS25.461 V6.0.0
Power	Standby	< 2 W
Consumption	In Motion	< 10 W
Connectors		2 x 8 Pin Circle Connector
		Pin3: RS485B; Pin5: RS485A; Pin6: 10-30 V; Pin7: DC Return
		Female Connector: 8 PINs; Male Connector: 4 PINs
Hardware Interfaces		RS485 and Power
Adjustment Time		≤ 90 sec (typical, depending on antenna type)
Adjustment Cycles		> 20,000
Torque Maximum		≥ 160 mN·m (@ 30RPM)
Lightning Protection Rating		IEC 61000-4-5 Current Pulse Profile
Lightning Protection Rating		Line to Ground: 8/20 µs @ 8 kA ≥ ±5
Remote Control		Can manage from OMC, BTS/Node B
Daisy Chaining Method		Ready for daisy-chaining
Safety Standard		Compliant to EN 60950/UL 60950/RoHS, CE
Housing Material / Color		Aluminum / Grey
Operating Temperature		-40° to +70° C (-40° to +158° F)
Storage Temperature		-55° to +75° C (-67° to +167° F)
Humidity		Up to 95%
IP Rating		IP65
Weight		≤ 500 g

Mechanical Specifications
Connector Type		—	(6x) 4.3/10 Female
Connector Position		—	Bottom
Electrical Tilt Control		—	Integrated RET
Radome Material		—	Fiberglass
Antenna Dimensions (H x W x D)		mm (in)	997 x 397 x 157 (39.3 x 15.6 x 6.2)
Antenna Weight	Antenna Only	kg (lbs)	15.5 (34.2)
Antenna Weight	with Clamps	kg (lbs)	20 (44.1)
Maximum Wind Speed		km/h (mph)	200 (124.3)
Wind Load	Frontal	N (lbf)	365 (82.1)
at 150 km/h	Rear	N (lbf)	410 (92.2)
	Lateral	N (lbf)	180 (40.5)
Operating Temperature		°C (°F)	-40 to +60 (-40 to +140)
