Product code: MT-DTA771
850-880MHz Cavity Band Pass Filter
- P/N：MT-DTA771
- Pass Band Frequency：850-880MHz
- Pass Band Frequency：850-880MHz
- Connectors：SMA-Female
Product Part Number
MT-DTA771
Electrical & Mechanical Specification
| S/N | Item | Parameters |
|---|---|---|
| 1 | Center Frequency(F0) | 865MHz |
| 2 | Pass Band Frequency | 850 ~ 880MHz |
| 3 | Pass Band Insertion Loss | ≤1.5dB |
| 4 | Pass Band Ripple | ≤0.8dB |
| 5 | Pass Band Return Loss | ≥20dB |
| 6 | Stop Band Rejection | ≥60dB @ DC ~ 830MHz @ 900 ~ 2500MHz |
| 7 | Impedance | 50 Ohms |
| 8 | Power Handling | 20W Max. |
| 9 | Connectors | SMA-Female |
