Product code: MT-868M06-NF

868 MHz LoRa Antenna 6dBi Omni Directional (EU868) N-Female

Product Overview
Part Number MT-868M06-NF
Dimension 1200x70x55mm
Weight 586g
Connector  N-Female
Beam-width Horz.360 deg Vert.25 deg



WhatsApp Chat
Skype
Product Part Number
MT-868M06-NF
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range860 to 870MHz
V.S.W. RAVG 1.5:1
Antenna TypeCollinear
RadiationOmni Directional
Gain (MAX)6 dBi
Antenna Factor24 dB/m
PolarizationVertical
Maximum Power50 Watts
Vertical Beam-width14 Deg
Horizontal Beam-width360 Deg
Impedance50 Ohm
Antenna DesignDipole Array
Internal MaterialCopper
ConnectorN-Female
Mechanical
Length 1200mm
Diameter 70x55mm
Antenna Weight 586g
Accessories 70g
ApplicationIndoor / Outdoor
Radom MaterialWhite Fiberglass
Parts MaterialAluminium
Mount StylePole Mount / Wall Mount
MountingStainless Steel
Wind SurvivalGreater than 150MPH
Storage Temperature-20 to +80
Operating Temperature-20 to +60
Operating Humidity10%~80% non-condensing
Storage Humidity5%~80% non-condensing
Safety, Emission and otherCE, FCC, RoHS
