Product code: MT-868M08-NF

868 MHz LoRa Antenna 8dBi Omni Directional N-Female connector

Product Overview
Part Number MT-868M08-NF
Dimension 1475x70x50mm
Weight 1070g
Connector  N-Female
Beam-width Horz.360 deg Vert.13 deg





WhatsApp Chat
Skype
Product Part Number
MT-868M08-NF
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range860 to 870MHz
V.S.W.R (MAX)868MHz: 1.5:1
860 and 870MHz: <2.0
Antenna TypeCollinear
RadiationOmni Directional
Gain (MAX)8 dBi
PolarizationVertical
Maximum Power50 Watts
Vertical Beam-width13 Deg
Horizontal Beam-width360 Deg
Impedance50 Ohm
Antenna DesignDipole Array
Internal MaterialCopper
ConnectorN-Female
Mechanical
Length1475+/-5 mm
Diameter70 x 50mm
Antenna Weight1000 g
Accessories70 g
ApplicationIndoor / Outdoor
Radom MaterialWhite Fiberglass
Parts MaterialAluminium
Mount StylePole Mount / Wall Mount
MountingStainless Steel
Wind SurvivalGreater than 150MPH
Storage Temperature-20 to +80
Operating Temperature-20 to +60
Operating Humidity10%~80% non-condensing
Storage Humidity5%~80% non-condensing
Safety, Emission and otherCE, FCC, RoHS
