Product code: MT-868M03-NM

868MHz 3dBi Mini Omni Directional Outdoor Antenna (N-Male)

Product Overview
Part Number MT-868M03-NM
Dimension 295x20x20mm
Weight 180g
Connector  N-Female
Beam-width Horz.360 deg Vert.110 deg



WhatsApp Chat
Skype
Product Part Number
MT-868M03-NM
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range860 to 870MHz
V.S.W.R (MAX)868MHz: 1.5:1
860 and 870MHz: <2.0
Antenna TypeCollinear
RadiationOmni Directional
Gain (MAX)3 dBi
PolarizationVertical
Maximum Power100 Watts
Vertical Beam-width110 Deg
Horizontal Beam-width360 Deg
Impedance50 Ohm
Antenna Design1/4 Wavelength Dipole
Internal MaterialCopper
ConnectorN-Male
Mechanical
Length (MAX)295mm
Diameter (MAX)24mm
Antenna Weight (G.W)180 g
Accessories (G.W)3g
ApplicationIndoor / Outdoor
Radom MaterialWhite Fiberglass
Parts MaterialCopper
Wind SurvivalGreater than 150MPH
Storage Temperature-20 to +80
Operating Temperature-20 to +60
Operating Humidity10%~80% non-condensing
Storage Humidity5%~80% non-condensing
Safety, Emission and other RoHS
