Product code: MT-8996M12-NF

890MHz to 960MHz 12dBi Vertical Omni Directional Outdoor Antenna N-Female

Product Overview
Part Number MT-8996M12-NF
Dimension 3000x70x55mm
Weight 2570g
Gain 12 dBi
Connector  N-Female
Beam-width Horz.360 deg Vert.6 deg



WhatsApp Chat
Skype
Product Part Number
MT-8996M12-NF
Electrical & Mechanical Specification
Specification
Electrical
Frequency Range890 to 960MHz
V.S.W.R (MAX)1.5:1
Antenna TypeCollinear
RadiationOmni Directional
Gain (MAX)12 dBi
PolarizationVertical
Maximum Power200 Watts
Vertical Beam-with6 Deg
Horizontal Beam-with360 Deg
Impedance50 Ohm
Antenna DesignDipole Array Dipole
Internal MaterialCopper
ConnectorN-Female
Mechanical
Length (MAX)3000 mm
Diameter (MAX)70 x 55mm
Antenna Weight (G.W)2500 g
Accessories (G.W)70 g
ApplicationIndoor / Outdoor
Radome MaterialWhite Fiberglass
Parts MaterialAluminium
Mount StylePole Mount / Well Mount
Pole Mounting32mm to 45mm
MountingStainless Steel
Wind SurvivalGreater then 100MPH
Storage Temperature-40 to +80
Operating Temperature-40 to +60
Operating Humidity10%~90% non-condensing
Storage Humidity5%~90% non-condensing
Safety, Emission and otherCE, FCC, RoHS
