Product code: MT-10M3G-44-20
Low Noise Amplifier 0.01-3GHz, NF:2.0dB, Gain:44dB,P1dB:20dBm
| Model: MT-10M3G-44-20 |
| Ultra Wide Band: 0.01-3GHz |
| Gain: 44dB Typ |
| Noise Figure: 2.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
Low Noise Amplifier 0.01-18GHz, NF:3.0dB, Gain:30dB,P1dB:21dBm 18-40GHz,NF:5.5dB,Gain:29dB,P1dB:19dBm
Low Noise Amplifier, 50KHz-20GHz, NF:2.5dB, Gain:18dB,P1dB:15dBm
Low Noise Amplifier 30MHz-6GHz, NF:3.0dB, Gain:35dB, P1dB:15dBm
Low Noise Amplifier , 50KHz-67GHz, NF:5.0dB, Gain:12dB,P1dB:15dBm
Low Noise Amplifier 50KHz-50GHz, NF:6dB, Gain:32dB,P1dB:19dBm
Low Noise Amplifier 50KHz-43GHz, NF:5.0dB, Gain:30dB
Low Noise Amplifier , 0.01-50GHz, NF:5.0dB, Gain:50dB,P1dB:13dBm
Low Noise Amplifier 0.3-20GHz, NF:3.0dB, Gain:14dB,P1dB:11dBm
Low Noise Amplifier 0.1-26GHz, NF:4.0dB, Gain:28dB,P1dB:21dBm
Low Noise Amplifier 0.1-18GHz, NF:2.5dB, Gain:30dB,P1dB:16dBm
