Product code: MT-0.1G26G-28-50
Low Noise Amplifier 0.1-26GHz, NF:4.0dB, Gain:28dB,P1dB:21dBm
| Model: MT-0.1G26G-28-50 |
| Ultra Wide Band:1-26GHz |
| Gain: 28dB Typ |
| Noise Figure: 4.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
Low Noise Amplifier 0.9-2.5GHz, NF:1.5dB, Gain:15dB,P1dB:15dBm
Low Noise Amplifier 0.5-6GHz, NF:2.5dB, Gain:33dB,P1dB:20dBm
Low Noise Amplifier 0.01-40GHz, NF:4.5dB, Gain:27dB,P1dB:21dBm
Low Noise Amplifier 0.1-3GHz, NF:1.0dB, Gain:28dB,P1dB:17dBm
Low Noise Amplifier 0.3-20GHz, NF:3.0dB, Gain:14dB,P1dB:11dBm
Low Noise Amplifier 0.1-18GHz, NF:2.5dB, Gain:30dB,P1dB:16dBm
Low Noise Amplifier,0.01-67GHz, NF:5.0dB, Gain:18dB,P1dB:15dBm
Low Noise Amplifier,0.01-67GHz, NF:5.0dB, Gain:25dB,P1dB:15dBm
Low Noise Amplifier 50KHz-67GHz,NF:5.0dB,Gain:25dB,P1dB:15dBm
Low Noise Amplifier 50KHz-20GHz,NF:3.0dB, Gain:30dB, P1dB:15dBm
