Product code: MT-0.1G3G-28-10
Low Noise Amplifier 0.1-3GHz, NF:1.0dB, Gain:28dB,P1dB:17dBm
| Model: MT-0.1G3G-28-10 |
| Ultra Wide Band: 1-3GHz |
| Gain: 28dB Min |
| Noise Figure: 1.0dB Max |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
