Product code: MT-0.5G67G-25-50
Low Noise Amplifier 0.5-67GHz, NF:5.0dB, Gain:25dB,P1dB:15dBm
| Model: MT-0.5G67G-25-50 |
| Ultra Wide Band: 5-67GHz |
| Gain: 25dB Typ |
| Noise Figure: 5.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
Low Noise Amplifier, 50KHz-50GHz, NF:5.5dB, Gain:38dB,P1dB:14dBm
Low Noise Amplifier, 50KHz-20GHz, NF:2.5dB, Gain:18dB,P1dB:15dBm
Low Noise Amplifier 50KHz-20GHz, NF:3.0dB, Gain:35dB, P1dB:15dBm
Low Noise Amplifier 0.03-6GHz, NF:3.0dB, Gain:25dB,P1dB:15dBm
Low Noise Amplifier 5-700MHz, NF:1.5dB, Gain:24dB,P1dB:23dBm
Low Noise Amplifier , 50KHz-67GHz, NF:5.0dB, Gain:12dB,P1dB:15dBm
Low Noise Amplifier 0.3-20GHz, NF:3.0dB, Gain:14dB,P1dB:11dBm
Low Noise Amplifier 50KHz-67GHz,NF:5.0dB,Gain:25dB,P1dB:15dBm
Low Noise Amplifier 50KHz-20GHz,NF:3.0dB, Gain:30dB, P1dB:15dBm
Low Noise Amplifier 0.1-26.5GHz, NF:6.0dB, Gain:18dB,P1dB:14dBm
