Product code: MT-1G40G-40-45
Low Noise Amplifier 1-40GHz, NF:4.5dB, Gain:43dB,P1dB:20dBm
| Model: MT-1G40G-40-45 |
| Ultra Wide Band: 1-40GHz |
| Gain: 43dB Typ |
| Noise Figure: 5.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
