Product code: MT-10G67G-30-50
Low Noise Amplifier 10-67GHz, NF:5.0dB, Gain:30dB,P1dB:13dBm
| Model: MT-10G67G-30-50 |
| Ultra Wide Band: 10-67GHz |
| Gain: 30dB Typ |
| Noise Figure: 5.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
Low Noise Amplifier 50KHz-20GHz, NF:3.0dB, Gain:35dB, P1dB:15dBm
Low Noise Amplifier 0.03-6GHz, NF:3.0dB, Gain:25dB,P1dB:15dBm
Low Noise Amplifier 50KHz-43GHz, NF:5.0dB, Gain:30dB
Low Noise Amplifier 0.3-20GHz, NF:3.0dB, Gain:14dB,P1dB:11dBm
Low Noise Amplifier 0.1-26GHz, NF:4.0dB, Gain:28dB,P1dB:21dBm
Low Noise Amplifier 0.1-18GHz, NF:2.5dB, Gain:30dB,P1dB:16dBm
Low Noise Amplifier 0.1-4GHz, NF:2.0dB, Gain:36dB,P1dB:10dBm
Low Noise Amplifier,0.01-67GHz, NF:5.0dB, Gain:18dB,P1dB:15dBm
Low Noise Amplifier,0.01-67GHz, NF:5.0dB, Gain:25dB,P1dB:15dBm
Low Noise Amplifier , 0.01-26.5GHz, NF:4.0dB, Gain:32dB,P1dB:20dBm
