Product code: MT-10G67G-30-50
Low Noise Amplifier 10-67GHz, NF:5.0dB, Gain:30dB,P1dB:13dBm
| Model: MT-10G67G-30-50 |
| Ultra Wide Band: 10-67GHz |
| Gain: 30dB Typ |
| Noise Figure: 5.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
Low Noise Amplifier 0.01-18GHz, NF:3.0dB, Gain:30dB,P1dB:21dBm 18-40GHz,NF:5.5dB,Gain:29dB,P1dB:19dBm
Low Noise Amplifier, 50KHz-20GHz, NF:2.5dB, Gain:18dB,P1dB:15dBm
Low Noise Amplifier 0.01-3GHz, NF:2.0dB, Gain:44dB,P1dB:20dBm
Low Noise Amplifier,0.03-6GHz, NF:2.0dB, Gain:38dB,P1dB:13dBm
Low Noise Amplifier 50KHz-43GHz, NF:5.0dB, Gain:15dB
Low Noise Amplifier , 50KHz-67GHz, NF:5.0dB, Gain:12dB,P1dB:15dBm
Low Noise Amplifier 50KHz-43GHz, NF:5.0dB, Gain:30dB
Low Noise Amplifier , 0.01-50GHz, NF:5.0dB, Gain:50dB,P1dB:13dBm
Low Noise Amplifier,0.01-67GHz, NF:5.0dB, Gain:25dB,P1dB:15dBm
Low Noise Amplifier 50K-53GHz, NF:5.0dB, Gain:12dB
