Product code: MT-11.75G12.75G-35-13
Low Noise Amplifier ,11.75-12.75GHz, NF:1.3dB, Gain:35dB,P1dB:15dBm
| Model: MT-11.75G12.75G-35-13 |
| Ultra Wide Band: 11.75-12.75GHz |
| Gain: 35dB Min |
| Noise Figure: 1.3dB Max |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
Low Noise Amplifier 0.01-18GHz, NF:3.0dB, Gain:30dB,P1dB:21dBm 18-40GHz,NF:5.5dB,Gain:29dB,P1dB:19dBm
Low Noise Amplifier 30MHz-6GHz, NF:3.0dB, Gain:35dB, P1dB:15dBm
Low Noise Amplifier 0.03-6GHz, NF:3.0dB, Gain:25dB,P1dB:15dBm
Low Noise Amplifier,0.03-6GHz, NF:2.0dB, Gain:38dB,P1dB:13dBm
Low Noise Amplifier 50KHz-43GHz, NF:5.0dB, Gain:15dB
Low Noise Amplifier , 50KHz-67GHz, NF:5.0dB, Gain:12dB,P1dB:15dBm
Low Noise Amplifier 50KHz-50GHz, NF:6dB, Gain:32dB,P1dB:19dBm
Low Noise Amplifier 0.3-20GHz, NF:3.0dB, Gain:14dB,P1dB:11dBm
Low Noise Amplifier 0.1-4GHz, NF:2.0dB, Gain:36dB,P1dB:10dBm
Low Noise Amplifier , 0.01-26.5GHz, NF:4.0dB, Gain:32dB,P1dB:20dBm
