Product code: MT-18G40G-36-30
Low Noise Amplifier 18-40GHz, NF:3.0dB, Gain:36dB,P1dB:15dBm
| Model: MT-18G40G-36-30 |
| Ultra Wide Band: 18-40GHz |
| Gain: 36dB Typ |
| Noise Figure: 3.0dB Max |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
