Product code: MT-18G40G-40-35
Low Noise Amplifier 18-40GHz, NF:3.0dB, Gain:43dB,P1dB:15dBm
| Model: MT-18G40G-40-35 |
| Ultra Wide Band: 18-40GHz |
| Gain: 43dB Typ |
| Noise Figure: 3.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
