Product code: MT-2G40G-30-45
Low Noise Amplifier 2-40GHz, NF:5.5dB, Gain:30dB,P1dB:19dBm
| Model: MT-2G40G-30-45 |
| Ultra Wide Band:2-40GHz |
| Gain: 30dB Typ |
| Noise Figure: 5.5dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
