Product code: MT-26G40G-35-50
Low Noise Amplifier 26-40GHz, NF:5.0dB, Gain:35dB,P1dB:21dBm
| Model: MT-26G40G-35-50 |
| Ultra Wide Band: 26-40GHz |
| Gain: 35dB Min |
| Noise Figure: 5.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
