Product code: MT-30M6G-35-30
Low Noise Amplifier 30MHz-6GHz, NF:3.0dB, Gain:35dB, P1dB:15dBm
| Model: MT-30M6G-35-30 |
| Ultra Wide Band: 30MHz-6GHz |
| Gain: 35dB Typ |
| Noise Figure: 3.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
Low Noise Amplifier 0.5-6GHz, NF:2.5dB, Gain:33dB,P1dB:20dBm
Low Noise Amplifier, 50KHz-20GHz, NF:2.5dB, Gain:18dB,P1dB:15dBm
Low Noise Amplifier 0.03-6GHz, NF:3.0dB, Gain:25dB,P1dB:15dBm
Low Noise Amplifier,0.03-6GHz, NF:2.0dB, Gain:38dB,P1dB:13dBm
Low Noise Amplifier 50KHz-50GHz, NF:6dB, Gain:32dB,P1dB:19dBm
Low Noise Amplifier , 0.01-50GHz, NF:5.0dB, Gain:50dB,P1dB:13dBm
Low Noise Amplifier 0.1-26GHz, NF:4.0dB, Gain:28dB,P1dB:21dBm
Low Noise Amplifier,0.01-67GHz, NF:5.0dB, Gain:18dB,P1dB:15dBm
Low Noise Amplifier,0.01-67GHz, NF:5.0dB, Gain:25dB,P1dB:15dBm
Low Noise Amplifier 50KHz-20GHz,NF:3.0dB, Gain:30dB, P1dB:15dBm
