Product code: MT-30M6G-35-30
Low Noise Amplifier 30MHz-6GHz, NF:3.0dB, Gain:35dB, P1dB:15dBm
| Model: MT-30M6G-35-30 |
| Ultra Wide Band: 30MHz-6GHz |
| Gain: 35dB Typ |
| Noise Figure: 3.0dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
