Product code: MT-35G50G-44-20
Low Noise Amplifier 35-50GHz, NF:2.5dB, Gain:44dB,P1dB:12dBm
| Model: MT-35G50G-44-20 |
| Ultra Wide Band: 35-50GHz |
| Gain: 44dB Typ |
| Noise Figure: 2.5dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
Low Noise Amplifier 0.5-6GHz, NF:2.5dB, Gain:33dB,P1dB:20dBm
Low Noise Amplifier, 50KHz-20GHz, NF:2.5dB, Gain:18dB,P1dB:15dBm
Low Noise Amplifier 30MHz-6GHz, NF:3.0dB, Gain:35dB, P1dB:15dBm
Low Noise Amplifier 5-700MHz, NF:1.5dB, Gain:24dB,P1dB:23dBm
Low Noise Amplifier,0.03-6GHz, NF:2.0dB, Gain:38dB,P1dB:13dBm
Low Noise Amplifier , 50KHz-67GHz, NF:5.0dB, Gain:12dB,P1dB:15dBm
Low Noise Amplifier 50KHz-43GHz, NF:5.0dB, Gain:30dB
Low Noise Amplifier , 0.01-50GHz, NF:5.0dB, Gain:50dB,P1dB:13dBm
Low Noise Amplifier 0.1-26GHz, NF:4.0dB, Gain:28dB,P1dB:21dBm
Low Noise Amplifier 0.1-26.5GHz, NF:6.0dB, Gain:18dB,P1dB:14dBm
