Product code: MT-35G50G-35-35
Low Noise Amplifier 35-50GHz, NF:3.5dB, Gain:35dB,P1dB:15dBm
| Model: MT-35G50G-35-35 |
| Ultra Wide Band: 35-50GHz |
| Gain: 35dB Typ |
| Noise Figure: 3.5dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
