Product code: MT-50K50G-33-60
Low Noise Amplifier 50KHz-50GHz, NF:6dB, Gain:32dB,P1dB:19dBm
| Model: MT-50K50G-33-60 |
| Ultra Wide Band: 50KHz-50GHz |
| Gain: 32dB Typ |
| Noise Figure: 6dB Typ |
| Good Power and Gain Flatness |
| 50 Ohm Matched Input / Output |
