Product code: MT-440-7dBi-140

380-4000MHz Directional Wall Mount Panel Antennas

Part No: MT-440-7dBi-140
Wide Frequency Band 380-4000MHz
 Low VSWR
High Gain
Widely used for DAS
WhatsApp Chat
Skype
Product Part Number
MT-440-7dBi-140
Electrical & Mechanical Specification
Electrical Specifications
Frequency Range(MHz)380-520698-9601710-27003300-4000
Gain(dBi)4.0±15.0±17.0±17.5±1
VSWR≤3.0≤2.0≤2.0≤2.0
PolarizationVertical
PIM, 3rd Order, 2x2W(dBc)≤-140
Horizontal Beamwidth150°90°75°65°
Vertical Beamwidth75°65°65°60°
Input Impedance50 Ω
Max. Input Power50 W
Lightning ProtectionDC Ground
Mechanical Specifications
ConnectorN | 4.3-10 Female
Dimensions(mm)315x195x68
Weight(kg)0.5
Reflector MaterialAluminum
Radome MaterialABS (UV Stabilized)
Operating Temperature-40°C to +65°C
