Product code: MT-923M03-NF
Mini Omni Directional Outdoor Antenna 923 MHz 3dbi
| Product Overview | |
| Part Number | MT-923M03-NF |
| Dimension | 320x30x30mm |
| Weight | 220g |
| Connector | N-Male |
| Beam-width | Horz.360 Deg Vert.58 Deg |
Product Part Number
MT-923M03-NF
Electrical & Mechanical Specification
| Specification | |
|---|---|
| Electrical | |
| Frequency Range | 900 to 945 MHz |
| V.S.W. R | < 1.5:1 |
| Antenna Type | Collinear |
| Radiation | Omnidirectional |
| Gain (AVG) | 3 dbi |
| Polarization | Vertical |
| Maximum Power | |
| -3db Horizontal beamwidth | 360 deg |
| -3db Vertical beamwidth | 73 deg |
| Impedance | 50 Ohm |
| Antenna Design | Dipole |
| Connector | N-Female |
| Mechanical | |
| Length | 320mm |
| Diameter | 30x30mm |
| Antenna Weight | 220 g |
| Application | Indoor / Outdoor |
| Radome Material | White Fiberglass |
| Parts Material | Copper |
| Wind Survival | Greater than 180MPH |
| Storage Temperature | -40 to +80 |
| Operating Temperature | -40 to +60 |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Safety, Emission and other | RoHS |
