Product code: MT-155165MMA

MT-155165MMA/Marine VHF Antenna

Model : MT-155165MMA
Frequency range: 155-165 MHz
WhatsApp Chat
Skype
Product Part Number
MT-155165MMA
Electrical & Mechanical Specification
Electrical specifications
Frequency range155-162 MHz, VSWR < 1.5: 1 144-165 MHz, VSWR < 2 : 1
Nominal impedance50 ohm
Power rating100 W
Gain2 dbi
PatternHorizontal plane: Omnidirectional Vertical plane: See page 2
PolarizationVertical
ConnectorUHF female or N Type female
DC-groundedYes
Mechanical specifications
DesignCentered coaxial dipole. Radiating elements completely enclosed in polyurethane foam within a fiberglass tube.
Height1.23m
Weight0.5 kg
Wind rating55 m/s = 125 mph
FinishPolyurethane lacquer, white
Temperature range-55 °C, +55 °C; -67 °F, +131°F
Water ProofingIP67
