Product code: MT-230M5MHA
MT-230M5MHA/16’Marine HF Antenna
| Model:MT-230M5MHA |
| Frequency range:1.6-30 MHz |
Product Part Number
MT-230M5MHA
Electrical & Mechanical Specification
| Electrical specifications | |
|---|---|
| Frequency range | 1.6-30 MHz |
| Power rating | 1 kW PEP |
| Static capacitance | 50 pF @ 2MHz |
| Polarization | Vertical |
| Pattern | Omnidirectional |
| Electrical length | (4.6 m) 15.1 ft |
| Feed system | Open wire, side fed |
| Mechanical specifications | |
| Design | Fiberglass whip in three sections. Stainless steel. |
| Height | 16’ (4,9 m) |
| Weight | 3.5 kg |
| Sections | Base: 8 ft (2.45 m) Top whip: 8 ft (2.45 m) |
| Wind rating | 55 m/s = 125 mph |
| Moment of flexure | 40 kpm at 55 m/s |
| Deflection due to wind load | 3 m (10 ft) at tip ball with 55 m/s wind load |
| Finish | Polyurethane lacquer, white (other colors on request. Chrome plated fittings |
| Temperature range | -55 0C, +71 0C, -67 0F, +160 0F |
| Ice build-up | Not affected |
