Product code: MT-230MNLA

MT-230MNLA/HF NVIS Loop Antenna

Model :MT-230MNLA
Frequency range:1.6-30 MHz
WhatsApp Chat
Skype
Product Part Number
MT-230MNLA
Electrical & Mechanical Specification
Electrical specifications
Frequency range1.6 – 30 MHz
Impedance1 to 1000 ohm, 50 ohm nominal
Power rating500 W PEP and average
Gain-10 dBi @ 3.5 MHz, -4 dBi @ 10 MHz
Radiation patternSee diagrams overleaf
Power supply18—32 VDC, normally supplied from power amplifier
Connector10 mm stud for RF MIL-C-5015, 7pin for interface to ATU and supply voltage
InterfaceThe antenna has two digital inputs and one output, and a RS485 serial port. Software is then configured depending on radio system
Mechanical specifications
DesignDouble 20 mm aluminum radiating element with 8 support rods. Enclosure made from fiberglass.
SizeEnclosure: 80 x 40 cm (H x W) Radiating loop: 2 x2 m
WeightTotal: <40 kg
Wind rating55 m/s = 125 mph
FinishPolyurethane lacquer, normally grey.
EnvironmentalTest method Per MIL-STD-810F Shock & Vibration Ship Water resistance IP67 Temperature range -40° to +71°C
InstallationSee installation drawing
