Product code: MT-AHLX2.8-30T
MT-AHLX2.8-30T
| Model : MT-AHLX2.8-30T |
| Frequency Range : 2.8-30 MHz |
| Impedance : 50 Ω |
| Temperature Range : -40° to +70°C |
| Connector : EIA 1.5/8″ |
Product Part Number
MT-AHLX2.8-30T
Electrical & Mechanical Specification
| Specification: | |||
|---|---|---|---|
| Frequency range | 2.8 to 30 MHz | Dimensions on ground | 6 m |
| Impedance | 50 Ω | Trapezium (LB x SB x H) | 77 x 25 x 41 m |
| VSWR in the band | < 2.8 | Staying | Ø 10 m |
| Maximum Gain | 6 – 8.5 dBi | Mast height | 21 m |
| Polarization | Horizontal | Staying | 4 levels of 3 stays |
| Radiation pattern | See diagrams | Radiating array material | Stainless steel cables |
| Maximum input power | 10 kW cw (option 1 kW) | Deployment time (6 operators) | 2 hours |
| Connector | EIA 1.5/8’’ (option N f) | Wind speed resistance Temperature range Colour | 120 km/h without frost -40° to +70°C Army green (IR NATO 24×5) |
