Product code: MT144174MMA

MT144174MMA/4dBi VHF Marine Antenna

Model: MT144174MMA
Frequency range: 144-174 MHz
WhatsApp Chat
Skype
Product Part Number
MT144174MMA
Electrical & Mechanical Specification
Electrical specifications
Frequency range144 – 174 MHz
VSWR<2.5
Nominal impedance50 ohm
Power rating25 W
Gain4 dBi
PolarizationVertical
ConnectorN female
Mechanical specifications
DesignCenter fed coaxial dipole. Radiating element completely enclosed in polyurethane foam within a fiberglass tube. Mounting bracket in aluminum.
Height2.23 m
Weight1.4 kg
Wind rating55 m/s = 125 mph
FinishPolyurethane lacquer, white
Temperature range-40°C, +50°C;+ -28 °F, +122°F
