Product code: MT-92-96GHz-1
W Wavelength Band Thin Film Filter
| Model:MT-92-96GHz |
| High frequency, small size |
| Degree of inhibition, high flatness |
| Low loss, anti-high power |
| Operating temperature:-55℃~85℃ |
Product Part Number
MT-92-96GHz-1
Electrical & Mechanical Specification
| Performance Specifications | |
|---|---|
| Parameter | Specifications |
| Frequency | 92GHz~96GHz |
| VSWR | ≤1.8 |
| Insertion Loss | ≤3.5dB |
| Power | ≤10W |
| Impedance matching | 50 Ω |
| Out-of-Band Rejection | ≥50dB |
| Interface Type | 25 Micron gold wire bonding |
